Energy Storage 5kWh Pytes V5°
A new lithium iron phosphate battery with a capacity of 5 kWh, ideal for home energy storage systems.
- Next delivery: 30 November 2026
Product details
- Brand
- Pytes
- Reference
- 110402100135
Data Sheet
| Capacity (kWh) | Model (Rabat) |
|---|---|
| 5 kWh | Pytes V5° |
Description
Description
Pytes V5°
5kWh energy storage for home energy storage system
Optimize your photovoltaic installation with a reliable energy storage system
Meet Pytes V5°
Pytes V5° is the second generation of LiFePO4 batteries (51.2V 100Ah), designed with the idea of even smarter and more efficient energy storage. This model stands out with increased continuous charge and discharge current at 75A, which translates to better system stability.
Thanks to the application of innovative FPC technology (flexible printed circuits), Pytes engineers have managed to create a lighter construction and organize the internal wiring, while maintaining the compact RACK 3.2U format.
Pytes V5° Front Panel Schematic
Energy Storage PYTES for your home system
Increase your home's energy self-sufficiency and optimize the use of energy from photovoltaic panels
Safe and Reliable
- BMS Over Current Alarm
- Fuse 360A
- Short Current Protection
Long-lasting and Efficient
- ≥6000 cycles at 90% DOD, maintaining 80% capacity at 25℃
- >95% efficiency of the charge-discharge cycle
- 10 years warranty, up to 20 years designed lifespan
Certifications
- OEM Co-Listing Available
- UL9540 Ed.2 UL1973 UL9540A CEC
- SGIP CE IEC62619 UN38.3
Wide Compatibility
- Compatible with most inverter brands on the market
- Ideal for existing and new photovoltaic installations
- Works with popular hybrid inverter brands
Cell Contact System
- High Reliability
- Higher Energy Density
- Highly Integrated
- Significant level of safety
Web / App
- Real-time Monitoring
- Remote Update
- Data Visualization
- Error Detection
Heating System
- Keeps the battery working in the optimal temperature range
- Wider battery operating temperature range
- Over 10 years design life
- Low energy consumption - 170 W
Higher Charge/Discharge Rate
- Maximum Charge Current 100A
- Maximum Discharge Current 100A
- Peak Discharge Current 101-120A (3 min)
- Peak Discharge Current 121-200A (15 sec)
Specifications
Energy Storage 5kWh Pytes V5° |
|
|
Nominal Voltage |
51,2 V |
|
Voltage Range |
47,5 V ~ 57,6 V |
|
Capacity |
100Ah |
|
Nominal Energy |
5,12 kWh |
|
Recommended Charge/Discharge Current |
75A |
|
Max Continuous Charge/Discharge Current |
100A |
|
Peak Charge/Discharge Current |
101A~120A (3 min) |
General |
|
|
Connection Option |
PHOENIX M6 Bolt |
|
Chemistry |
LFP |
|
Communication Protocol |
CAN/RS485 |
|
Dimensions (L × W × H) |
442 x 530 x 140 mm (3,2 U) |
|
Weight |
44 kg / 97 lbs |
|
Ambient Temperature |
-10°C~50°C / 14°F~122°F |
|
Cycle Life |
≥6000 cycles |
|
Scalability |
16 pcs (81.92kWh) in a group |
|
Mounting Method |
Wall / Ground (W/ Optional Battery Tray) |
|
Heating System |
Temperature rise: 8°C/h / 14,4°F/h |
|
Warranty |
10 years |
|
Certifications |
UL9540 Ed.2 (2020), UL9540A, UL1973, CEC, SGIP, CE, IEC62619, UN38.3 |
