Communication Centre Ekrano GX
Ekrano GX is an advanced communication centre that opens up new possibilities for remote management. This flagship device from the GX range ensures full, reliable control over your entire energy installation.
- -39%
Product details
- Brand
- Victron Energy
- Reference
- BPP900480100
- EAN13
- 8719076058038
- MPN
- BPP900480100
Data Sheet
| Bluetooth | IP Rating | Safety | Automotive Directive | Zakres temperatury pracy | Normy EMC (emisja i odporność) | Napięcie zasilania | Mount | Wejścia cyfrowe | Porty komunikacyjne | Porty hosta USB | Gniazdo karty microSD | Wbudowany brzęczyk | Rozdzielczość wyświetlacza | VE.Direct | Wyjścia przekaźnikowe | Pobór mocy przy włączonym ekranie (100% jasności) | Pobór mocy przy wyłączonym ekranie | Rezystancyjne wejścia poziomu w zbiorniku | Wejścia temperatury w zbiorniku | Maks. jasność wyświetlacza | Regulacja jasności podświetlenia |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Yes | IP54 | IEC 62368-1 | ECE R10-6 | Od -20 do +50°C | EN 301489-1 EN 301489-17 | 8 - 70 V DC | Podtynkowy | 2 | Ethernet VE.Bus (1x z 2x RJ45) VE.Can (2x) VE.Direct (3x) Wi-Fi | 2x USB-A (maksymalnie 1.5 A przy 5 V łącznie) | Tak (karty SDHC o pojemności maks. 32 GB) | Tak | 1024 x 600 px | Yes | 2x NO/NC AC 1A 125VAC DC do 30VDC 3A | 6.2W @ 12V 6.6W @ 24V 7.4W @ 48V | 2.6W @ 12V 3.0W @ 24V 3.7W @ 48V | 3 | 2 | 1000 cd/m² | Tak |
Description
Ekrano GX
The gateway to independence
The modern Ekrano GX is an advanced communication hub that opens up new possibilities for remote management. This flagship device from the GX range ensures full, reliable control over your entire energy installation.
You can monitor all key data and analyses in real-time using the readable, seven-inch touch screen operating under the intuitive Venus system, with a rich array of connectors allowing seamless integration with any Victron system..
Remote management becomes easier with the VRM portal and VictronConnect app.
Key Features
Discover the advantages that make the difference
Waterproof Touch Screen
Durable Aluminum Enclosure
Extremely Efficient Processor
Remote VRM Monitoring
VictronConnect App
Integration with MFD and NMEA 2000
Rich Connectivity Options
Comprehensive solution for integrating all elements of your system
Designed for Operation in Any Conditions
Solid aluminum enclosure and waterproof 7-inch touch screen of the Ekrano GX provide full protection and reliable operation in any conditions, automatically switching to dark mode in low light, allowing you to instantly control the power system.
Maximizing System Efficiency
As a central communication hub, Ekrano GX uses a powerful processor and modern Venus operating system, to seamlessly coordinate the operation of all connected devices and elevate the overall system efficiency to a completely new level.
Engineering at the Highest Level
Key features and their operation
Exceptionally Efficient Processor
The four-core, exceptionally efficient processor of Ekrano GX effortlessly manages all connected Victron devices and equipment from other manufacturers.
Venus OS v3.0
The updated Venus OS 3.0 features an elegant design and refreshed color scheme, making system monitoring more intuitive than ever.
GX - Battery Compatibility
The GX device ensures seamless and trouble-free integration with the ever-growing list of leading lithium battery manufacturers.
Simple Installation and Setup
The exceptionally slim design with included mounting materials enables flexible wall mounting or in a box, maintaining easy access to ports from the back.
Waterproof
IP54 protection class with a mounted steel cover effectively protects the display from dust and water from the outside.
Touch Screen Disable Button
The hidden button on the back of the housing allows you to enable or disable the touch screen function at any time, preventing unauthorized use.
Venus OS - Digital Brain of the System
Discover the potential of the Venus OS, which transforms complex data into a clear picture of your installation. Just a few clicks are needed to configure all parameters, while advanced algorithms will take care of the rest.
Intuitive System Dashboard
One screen displaying all key indicators of your system. You will immediately notice how much energy you are drawing from the grid, how much is generated by your solar panels, the state of your batteries, and the fluid levels in your tanks - all presented in a clear overview.
Comprehensive energy analysis
Track the flow of energy in real-time with ease. Observe how the batteries are charging, how much power your devices are consuming, and how efficiently your energy sources are performing - from solar panels through the generator to the grid connection - all displayed on a single screen.
Advanced Resource Monitoring
Maintain full control over fluid levels and environmental parameters. Track the status of water, fuel, and waste tanks, as well as monitor temperature and humidity. The system will automatically alert you when any parameter approaches critical values.
Comprehensive System Management
Managing your system has never been easier. With a single tap, you can change the power draw limit, start or stop the generator, or switch the power source. The thoughtfully designed interface makes even complex operations intuitive.
Proactive Safety System
Peace of mind with intelligent alerts. The system continuously monitors all parameters and immediately notifies you of potential issues or anomalies. You decide which alerts are important to you and how the system should respond.
Full Remote Access via VRM
Ekrano GX opens the door to the world of remote management. By using the VRM portal, you can observe, configure, and control your system over the internet, as if you were standing right next to it.
- Comprehensive Remote Configuration - Adjust system parameters from any location without the need for physical access
- Flexibility of Access - Utilize the same features in a local network or through the device's own Wi-Fi access point
- Smart notifications - An alert system ensuring a rapid response to faults in the operation of the installation
Applications
High voltage where you need it.
Marine
Seamless integration with MFD and Signal K and NMEA 2000 data enable convenient yacht management directly from the bridge.
Energy Storage Systems
Planned charging and solar forecasts VRM allow you to optimize performance with respect to grid tariffs and more effectively save energy.
Off-Grid Systems
Prioritization of solar energy and automatic generator control minimize its usage and allow for noise period management.
Hybrid Generators
Remote monitoring of hundreds of systems, custom VRM widgets and Node-Red allow for efficient management of critical parameters and automation.
Data sheet
-
BluetoothYes
-
IP RatingIP54
-
Dimensions (W x H x D)187 x 124 x 29.8 mm
-
SafetyIEC 62368-1
-
Automotive DirectiveECE R10-6
-
Zakres temperatury pracyOd -20 do +50°C
-
Normy EMC (emisja i odporność)EN 301489-1
EN 301489-17 -
Napięcie zasilania8 - 70 V DC
-
MountPodtynkowy
-
Wejścia cyfrowe2
-
Porty komunikacyjneEthernet
VE.Bus (1x z 2x RJ45)
VE.Can (2x)
VE.Direct (3x)
Wi-Fi -
Porty hosta USB2x USB-A (maksymalnie 1.5 A przy 5 V łącznie)
-
Gniazdo karty microSDTak (karty SDHC o pojemności maks. 32 GB)
-
Wbudowany brzęczykTak
-
Rozdzielczość wyświetlacza1024 x 600 px
-
VE.DirectYes
-
Wyjścia przekaźnikowe2x NO/NC
AC 1A 125VAC
DC do 30VDC 3A -
Pobór mocy przy włączonym ekranie (100% jasności)6.2W @ 12V
6.6W @ 24V
7.4W @ 48V -
Pobór mocy przy wyłączonym ekranie2.6W @ 12V
3.0W @ 24V
3.7W @ 48V -
Rezystancyjne wejścia poziomu w zbiorniku3
-
Wejścia temperatury w zbiorniku2
-
Maks. jasność wyświetlacza1000 cd/m²
-
Regulacja jasności podświetleniaTak
Product Details
-
Brand
-
ReferenceBPP900480100
-
In stock1 Item
-
EAN138719076058038
-
MPNBPP900480100
