Inverter / Charger MultiPlus-II 12/5000/220-50 230V
MultiPlus-II is an advanced design from Victron Energy that combines the functions of an inverter and charger. It provides reliable power for domestic, commercial and off-grid installations. Thanks to its intelligent energy management, it enables seamless switching between sources and full integration with storage systems.
- On request
Product details
- Brand
- Victron Energy
- Reference
- PMP122505012
- EAN13
- 8719076016588
- MPN
- PMP122505012
Data Sheet
| Category | Model (Rabat) |
|---|---|
| Przetwornice | CUO |
Description
Description
MultiPlus-II 12/5000/220-50
Innovative power management system
MultiPlus-II is a modern inverter-charger designed for intelligent energy management. It provides stable and efficient power supply in residential, commercial, and off-grid systems, ensuring reliability in every situation.
Thanks to its advanced design, it offers seamless switching between power sources and full integration with storage systems. The device supports PowerControl and PowerAssist modes, ensuring stability even under high loads.
MultiPlus-II is an efficient, flexible solution that grows together with your system - whether you’re powering a home, workshop, or photovoltaic installation.
Introduction
The MultiPlus-II series forms the foundation of modern Victron Energy power systems. It combines inverter and charger functions, ensuring reliable energy management in residential, commercial, and off-grid applications.
Key Features
Intelligence, efficiency, control, reliability
Power Assist
MultiPlus-II automatically prevents overloading of power sources such as the grid or a generator. It first limits battery charging current and, if necessary, supplements power from the batteries to maintain stable supply without overloading the system.
UPS Backup Power
In case of a power outage, MultiPlus-II instantly switches to battery power, ensuring uninterrupted operation of connected devices. The switch occurs in less than 20 milliseconds, keeping even sensitive electronics running without interruption.
ESS
MultiPlus-II is a key component of the Victron ESS system, enabling flexible connection with MPPT solar chargers and Grid-tie PV inverters for smart energy management and optimal use of renewable sources.
Applications
A universal solution for various industries
Home and photovoltaic installations
Provides full integration with energy storage and solar chargers, increasing self-consumption of PV energy.
Off-grid and mobile systems
Ideal for powering locations without grid access – summer houses, RVs, and boats.
Emergency power for businesses and critical facilities
Ensures uninterrupted operation during power failures, protecting IT equipment and security systems.
Why MultiPlus-II?
Because it is one of the most versatile and reliable solutions in energy management. MultiPlus-II means stability, safety, and energy independence in one device, designed to operate reliably for years in any power configuration.
Monitoring and Control
Full system control
Remote access to the system anytime
When MultiPlus-II is connected to a GX device such as Cerbo GX or Ekrano GX, users gain full access to monitoring and configuration of the entire installation. The system can be managed locally via LAN or remotely over the Internet using the free Victron VRM app or VRM Online portal.
FAQ
Frequently Asked Questions
Specifications
MultiPlus-II 12/5000/220-50 230V |
|
|
PowerControl / PowerAssist |
Yes |
|
Automatic transfer switch |
50 A |
Max. AC input current |
50 A |
|
INVERTER |
|
|
DC input voltage range |
9.5 - 17 V |
|
AC output voltage and frequency (1) |
230 VAC ± 2%
|
|
Output power at 25°C (2) |
5000 VA |
Output power at 25°C |
4000 W |
Output power at 40°C |
3700 W |
Output power at 65°C |
3000 W |
|
Max. apparent power supply |
5000 VA |
Peak power |
9000 W |
Max. efficiency |
95% |
|
Zero load power |
15 W |
|
Zero load power in AES mode |
11 W |
|
Zero load power in search mode |
3 W |
|
CHARGER |
|
|
AC input voltage and frequency |
187 - 265 VAC
|
|
Absorption charge voltage |
14.4 V |
|
Float charge voltage |
13.8 V |
Storage mode |
13.2 V |
|
Max. battery charging current (3) |
220 A |
|
Battery temperature sensor |
Yes |
|
GENERAL |
|
|
Auxiliary output |
50 A |
|
External AC current sensor (option) |
50 A or 100 A |
|
Programmable relay (4) |
Yes |
|
Protection (5) |
a - g |
|
VE.Bus communication port |
For parallel, three-phase operation, remote monitoring and system integration |
|
General purpose communication port |
Yes, 2x |
|
Remote on/off |
Yes |
|
Operating temperature range |
-40 to +65°C
|
|
Humidity |
max. 95%
|
|
ENCLOSURE |
|
|
Material and color |
Steel (RAL 5012 color) |
|
Protection category |
IP 22 |
|
Battery connection |
M8 bolts |
|
230 VAC connection |
Screw terminals 13 mm² (6 AWG) |
|
Weight |
33 kg |
|
Dimensions, W x H x D |
702 x 345 x 152 mm |
|
STANDARDS |
|
Safety |
EN-IEC 60335-1,
|
Emissions, immunity |
EN 55014-1, EN 55014-2,
|
|
FOOTNOTES |
|
|
1) Can be adjusted to 60 Hz |
|
|
2) Non-linear load, crest factor 3:1 |
|
|
3) At ambient temperature of 25°C |
|
|
4)
Programmable relay can be set for general alarm, DC under-voltage or
generator start/stop.
|
|
|
5) Protections:
a) output short circuit
|
|
